MS3C-ProX, Frame Emergency Ambulance Stretcher
MS3C-ProX, Frame Emergency Ambulance Stretcher
MS3C-ProX, Frame Emergency Ambulance Stretcher
MS3C-ProX, Frame Emergency Ambulance Stretcher
MS3C-ProX, Frame Emergency Ambulance Stretcher

MS3C-ProX, Frame Emergency Ambulance Stretcher

Regular price $2,545.00
/

This ambulance stretcher is made out of commercial grade aluminum alloy. Specifically developed to aid EMS paramedics and emergency responders, it is designed to be durable, lightweight, easy to use and at a fraction of the cost of comparable brand name models

Features:
  • Adjustable height includes 7 locking positions
  • X-frame undercarriage is easily raised when loading
  • Constructed of high-strength aluminum alloy
  • Pneumatic Adjustable Backrest: 0 - 65 degrees
  • Locking side rails collapse for safe patient loading and unloading
  • Stretcher must be loaded with two emergency operators
  • Safety locking device keeps stretcher locked in place while the transport vehicle is in motion
  • When unloading, the safety U-bar will hold the stretcher on the ambulance until the operator releases it
  • Breakaway head section secured with hook and loop fasteners
  • (4) Safety locking 5.5in rubber casters
  • Max Vehicle Loading Height for this stretcher is 31" (distance from ground to loading platform: ie. van bumper or ambulance loading dock) see attached pdf for measuring instructions

Accessories Included:
  • 4 inch waterproof seamless welded PVC foam mattress
  • (3) Vest type belts for chest, hip, and knee
  • Transport Safety Locking Device Included
  • IV pole included

Positions Loading Height / Overall Height:

  • Position 1:  Ground /16in
  • Position 2:  8.5in / 24in
  • Position 3:  12.5in / 28in
  • Position 4: 16.5in / 32in
  • Position 5: 20. in / 36in
  • Position 6: 24in / 40in
  • Position 7: 27in / 43in
  • Position 8: 31in / 46in

Specifications:

  • High Position:78.75 X 22 X 39.25 in
  • Low Position:78.75 X 22 X 16 in
  • Maximum Angle of Backrest: 75 degrees
  • Maximum Angle of Legrest: 35 degrees
  • Weight Capacity: 550 lbs
  • Net Weight: 95 lbs

    Warranty: 1 Year

 FREE dock to dock commercial delivery only

Additional fees may apply for residential, limited access and/or liftgate deliveries
